The Eastern Veil Nebula
The Veil Nebula is about 2,000 light-years away in the constellation Cygnus.
September 2, 2025
Once again, I’m continuing the journey of exploring old targets with the Hyperstar. This time, I was able to gather about 5 hours of integration on the Eastern Veil. This time around, because of the tighter bandpasses on the Optolong filter, I was really able to capture some of the fainter bits of nebulosity along the front and rear of the bow shock. I once again opted for the Foraxx palette, which really adds some intensity to the color in the image. I ended up tossing out about 40 subframes - 30 of them due to some thin clouds that settled in over the area in the early morning hours, and 10 that had what clearly seemed to be some strange guiding behavior. I’m chalking that up to me forgetting to re-calibrate guiding before I started, and the mount using the last calibration from after the meridian flip on Cygnus wall last night. I also processed the image in the standard palette as well.
Speaking of my Cygnus Wall image, I think I’ve solved the mystery of the strange objects from the Cygnus wall image, as they appeared again in this one (bottom right by my signature)… they are definitely filter halo artifacts. Now the real mystery becomes, why are they only appearing around certain stars and not others? It’s clearly not correlated with magnitude, since the brighter, larger stars should also have halos as well. Once again, using Franklin Marek’s What’s In My Image tool, I found that the stars with halos in this image are of the same type as in the Cygnus Wall image… they are also Long Period Variable stars! I’d be curious to see an explanation of why Long Period Variable Stars are producing these odd haloing artifacts with this filter. I don’t know enough about them or F/2 filters to even make a guess. Hopefully someone who knows better can enlighten me!
Technical Details
Imaging Telescope: Celestron C9.25 XLT
Imaging Camera: ZWO ASI533MC Pro
Mount: Sky-Watcher EQ6-R Pro
Filter: Optolong L-eXtreme F2 2"
Accessories: Starizona Filter Drawer 2", Starizona HyperStar 9.25 v4, ZWO ASIAIR Plus, ZWO EAF
Software: StarNet, PixInsight, BlurXTerminator, NoiseXTerminator, SetiAstro Statistical Stretch, SetiAstro Star Stretch, Siril, ZWO ASIAIR
Guiding Telescope: SVBony SV106 60mm Guide Scope
Guiding Camera: ZWO ASI174MM
Imaging Dates: September 1, 2025
Frames (gain 101.0) f/4.9 -10c: 100x180” (5h)
Integration Time: 5h
November 30, 2023
Reprocessed my original data of the Eastern Veil using the new techniques in Siril. As with the others: better depth of color, better color balance, and better control of the star size. I also chose not to rotate it from the original field of view from the scope.
Technical Details
Imaging Telescope: William Optics RedCat 51 II
Imaging Camera: ZWO ASI533MC Pro
Mount: Sky-Watcher EQ6-R Pro
Filter: SVBony UV/IR Cut 2”
Accessories: ZWO ASIAIR Plus, ZWO EAF, ZWO Filter Drawer (Gen 2)
Software: Siril, Photoshop, NoiseXterminator, Starnet
Guiding Telescope: William Optics UniGuide 32
Guiding Camera: ZWO ASI174MM
Imaging Dates: Nov. 10, 2023
Frames: 70×120″(2h20m) (gain 101.0) f/4.9 -10c
Integration Time: 2h20m
Darks/Flats/Dark Flats: 30/30/30
Bortle Dark-Sky Scale: 4.00
November 12, 2023
My first image of the Eastern Veil Nebula, also known as Caldwell 33. This is a delicate area of nebulosity that’s a part of the Veil Nebula or Cygnus Loop region, the other side of which contains the Witch’s Broom. I plan to take a mosaic image of this entire region soon. Given there’s only 2 hours 20 mins of integration time, I’ve very happy with how this image turned out, but I would like to add some more integration time to help add details.
Technical Details
Imaging Telescope: William Optics RedCat 51 II
Imaging Camera: ZWO ASI533MC Pro
Mount: Sky-Watcher EQ6-R Pro
Filter: SVBony UV/IR Cut 2”
Accessories: ZWO ASIAIR Plus, ZWO EAF, ZWO Filter Drawer (Gen 2)
Software: DSS, Siril, Photoshop, AstroFlat Pro, NoiseXterminator, StarXterminator, Astronomy Tools Actions Set
Guiding Telescope: William Optics UniGuide 32
Guiding Camera: ZWO ASI174MM
Imaging Dates: Nov. 10, 2023
Frames: 70×120″(2h20m) (gain 101.0) f/4.9 -10c
Integration Time: 2h20m
Darks/Flats/Dark Flats: 30/30/30
Bortle Dark-Sky Scale: 4.00
